Fabric View

3–90

Web Tools Version 3.0.x/4.0.x User Guide

Delete Qloop

Click to delete a QuickLoop member.

Rename Qloop

Click to rename a QuickLoop member.

Switch Selection
List

This field displays a list of potential QuickLoop members,
including switches.

[QuickLoop]
Members

This field contains a list of the zone members selected in
the QuickLoop Name pull-down menu. The name on this
list depends on the name of the selected QuickLoop
member. If a name is not available, the name displays as
“null Members.”

< Search Mem

Click to search for a Domain or a switch name in the
Member Selection List based on the type of objects
displayed in that list.

Add Mem >

Click to add a member from the member selection list into
the [QuickLoop member] contents.

< Remove Mem

Click to remove a member from the [QuickLoop] members
list when selected.

Ref Zone

Click to refresh the local zoning database copied from the
switch. This button automatically flashes red/gray if the
fabric zoning data is changed by another client.

A/D WWN

Click to add or delete a WWN to or from all the aliases,
zones, and FA zones defined.

Rpl WWN

Click to replace a WWN with another one in all aliases,
zones, and FA zones defined.

OK

Click to apply the changes to the switch and exit the
switch.

Apply

Click to apply the changes to the switch.

Close

Click to exit the window without making any changes to
the switch.

Clr All

Select to clear the zoning database, disable the effective
configuration (if there is one), and then commit to the
switch.

Table 3–33: QuickLoop Tab Fields (Continued)
