Fabric View
–93 Web Tools Version 3.0.x/4.0.x User Guide 3–93
Add WWN Host > Click to add a WWN Host that is not currently part of
the Fabric.
Ref Zone Click to refresh the local zoning database copy from
the switch. This button would automatically flash
red/gray if the fabric zoning data is changed by
another client.
A/D WWN Click to add/delete a WWN to/from all the aliases,
zones, and FA zones defined.
Rpl WWN Click to replace a WWN with another one in all
aliases, zones, and FA zones defined.
Ok Select OK to apply the changes to the switch and
exit the window.
Apply Click to apply all changes made, including changes
made on other tabs in the view. Changes cannot be
cancelled once they are applied.
Close Click to exit the window without making any
changes to the switch.
Clr All Select to clear the zoning database, disable the
effective configuration (if there is one), and then
commit to the switch.
Table 3–34: WWN Fabric Assist Tab Fields (Continued)
