background image

Fabric View

3–21

Web Tools Version 3.0.x/4.0.x User Guide

3–21

Table 3–8 gives descriptions of the fields on the Port Zone tab.

Table 3–8: Port Zone Tab Fields

Zone Name

To modify an existing zone, select a zone name.

Create Zone

Select to create a new zone. A dialog displays in which you
can enter the name of the new zone. All names must be
unique and contain no spaces.

Delete Zone

Select to delete the zone selected in the Zone Name field.
Deleting a zone automatically removes it from all zone
configurations.

Rename Zone

Select to edit the name of the zone selected in the Zone
Name field. A dialog displays in which you can edit the
name of the zone.

Search Mem

Select to search the list of potential zone members.

Member
Selection List

A list of potential zone members, including switches, ports,
WWNs, aliases, and QuickLoop AL_PAs, and Fabric
Assists.

Add Mem

Select to add the member selected in the Member Selection
List to the Zone Members list. If an entire switch is selected,
all ports on the switch are added to the zone. You can also
select individual ports. To add a device WWN, select either
a node WWN (folder icon) or port WWN (blue circle icon)
from the WWNs sub-tree. To add an alias to the zone, select
it from the Aliases sub-tree (the alias must already exist).

Remove Mem

Select to remove the selected member from the Zone name
Members list.

[Zone name]
Members

This field lists members of the zone selected in the Zone
Name field. The name of this list depends on the name of
the selected zone. If no zone is selected, the name displays
as “null Members.”

Ref Zone

Click to refresh the local zoning database copied from the
switch. This button automatically flashes red/gray if the
fabric zoning data is changed by another client.

A/D WWN

Click to add or delete a WWN to or from all the aliases and
zones defined.

Rpl WWN

Click to replace a WWN with another one in all aliases and
zones defined.
