Remote switch tab (optional software), Remote switch tab (optional software) –75 – HP StorageWorks 2.32 SAN Switch User Manual
Page 231

–75
Web Tools Version 3.0.x/4.0.x User Guide
4–75
Remote Switch Tab (Optional Software)
Use the Remote Switch feature to configure a pair of switches to operate over an
extended WAN interface so that they can communicate across an ATM network by
using a compatible Fibre Channel-to-ATM gateway. This feature requires an active
Remote Switch license in both switches. For detailed information on the Remote
Switch feature, refer to the HP StorageWorks Extended Fabric Version 3.0.x/4.0.x
User Guide.
Use the Remote Switch tab to manage the Remote Switch option. This tab displays
only when the Remote Switch is installed. The Remote Switch tab is shown in
Figure 4–55.
Remove
Check to remove the specified license.
Close
Check to exit the current tab.
Any license key data that has been entered but not saved by
clicking either the Add or Remove button will be lost.
Reset
Click to reset the tab to the last set of committed changes. If
the Apply button has not been pressed on this tab, the
parameters are returned to the original values the tab had
when it was initially displayed.
Table 4–20: License Administration Tab Fields (Continued)
