Switch View
4–112 Web Tools Version 3.0.x/4.0.x User Guide
Table 4–34 provides a description of the fields on the Port Setting tab.
Table 4–34: Port Setting Tab Fields
Port Number Displays the Port Number.
Trunking
Enable:Disable Check to enable or uncheck to disable trunking. A maximum
of four trunk ports form a group, with one of them in the role
of master port, and the rest are member ports.
The Trunking column will only be displayed if the switch has
a Trunking License.
Port
Enable:Disable Check to enable or uncheck to disable ports on the switch.
Port State Displays the state of the port, such as Online, No Light or No
Module.
Current Speed Displays port speed. Port speed can be fixed to 1G, 2G, or
negotiate. If the speed is set to negotiate, the speed will
depend on the negotiated result.
Change Port
Speed Click the drop-down menu to change the port speed. Port
speed can be changed to 1G, 2G, or negotiate. If the speed
is set to negotiate, the speed will depend on the negotiated
result.
Slot Number tabs Click to view a specific slot.
The slot tabs will only appear when viewing an
StorageWorks Core switch series switch.
OK Click to save the changes made to the tab and to exit the
view.
Apply Click to save the changes made to this tab and to stay in the
current tab. Additional changes can be made and the Apply
button pressed when making changes incrementally.
Close Click to exit the current view.
Reset Click to reset the tab to the last set of committed changes. If
the Apply button has not been pressed on this tab, the
parameters are returned to the original values the tab had
when it was initially displayed.
Refresh Click to view the most current port settings information.
