background image

Fabric View

3–50

Web Tools Version 3.0.x/4.0.x User Guide

Table 3–18 gives descriptions of the fields on the AL_PA Device Zone tab.

Table 3–18: AL_PA Device Zone Tab Fields

Zone Name

Select an existing zone member to modify.

Create Zone

Click to create a new zone member.

Delete Zone

Click to delete a zone member.

Rename Zone

Click to rename a zone member.

Member Selection List

This field displays a list of potential zone members,
including switches, ports, WWNs, and QuickLoop
AL_PAs, and Fabric Assists.

Zone Members

This field lists the zone members selected in the Zone
Name
field. The name on this list depends on the name
of the selected zone member. If a name is not selected,
the name displays as “null Members.”

Search Mem

Click to search for a switch name, WWN, alias, zone, or
QuickLoop in the Member Selection List based on the
type of objects displayed in that list.

Add Device

Click to add a device that currently is not part of the
Fabric.

Add Mem

Click to add a member from the member selection list
into the Zone Members list.

Remove Mem

Click to remove a member from the Zone Members List
when selected.

Ref Zone

Click to refresh the local zoning database copied from
the switch. This button automatically flashes red/gray if
the fabric zoning data is changed by another client.

A/D WWN

Click to add or delete a WWN to or from all the aliases
and zones defined

Rpl WWN

Click to replace a WWN with another one in all aliases
and zones defined.

OK

Click to apply the changes to the switch and exit the
switch.

Apply

Click to apply the changes to the switch.

Close

Click to exit the window without making any changes to
the switch.
