Thresholds for the Environmental Classes

The Environmental classes are displayed by selecting the Environmental file from the
separate column left of the Configure Thresholds tab.

Thresholds for the SFP Classes

The SFP classes are displayed by selecting the SFP file from the separate column left
of the Configure Thresholds tab.

Table 4–3: Environmental Classes Thresholds

The columns for the Temperature, RX Power, TX Power and current areas
contain the following items:

Threshold Type
drop-down list

Select the threshold type (exceeded, above, in-between,
below, changed).

High/Low
drop-down list

Select to enter the high and low settings for the threshold
type selected in the Threshold Type drop-down list (not
available for all areas).

Area Select
checkbox

Select a Fabric Watch area to configure. Only one area can
be selected at a time.

Thresh element
drop-down list

Check or uncheck to specify if you want this element to be
monitored.

The column for the Power Supply area contains the following item:

“Send alarms
when” box

Use this text box to specify whether you want to be notified
when the area is in the acceptable range (OK) or is faulty
(FAULTY).

Table 4–4: SFP Classes Thresholds

The columns for the Temperature, RX Power, TX Power and current areas
contain the following items:

Threshold Type
drop-down list

Select the threshold type (exceeded, above, in-between,
below, changed).

High/Low
drop-down list

Select to enter the high and low settings for the threshold
type selected in the Threshold Type drop-down list (not
available for all areas).

Scale

Specify the point at which you want to set the specified
threshold.
