Switch View
4–122 Web Tools Version 3.0.x/4.0.x User Guide
Log Area Displays coded messages:
Successful changes to settings are logged in italics.
Error messages are indicated in red.
Warning messages are indicated in orange.
Additional information is indicated in magenta.
QuickHelp Status
bar Displays a one-line description about entry fields or a tool
tip on any modifiable component. A green icon indicates
that a switch is enabled; a red icon is displayed when the
switch is disabled using the Admin tool.
Table 4–39: Routing Tab Fields (Continued)
