Port information view fields –3 – HP StorageWorks 2.32 SAN Switch User Manual
Page 291

Port View
5–3
Web Tools Version 3.0.x/4.0.x User Guide
5–3
Table 5–1 provides a description of the fields that are visible in Port Information View,
regardless of which tab is selected.
Table 5–1: Port Information View Fields
Numbered
Tabs
Select to view information on a
specific port.
Port World
Wide Name
Displays the World Wide Name
(WWN) of this port.
Port Module
The SFP type, as follows:
--
No SFP present
SW
Short wave SFP
LW
Long wave SFP
CU
Copper SFP
SWID
Long wave serial ID SFP
LWID
Long wave serial ID SFP
CUID
Copper serial ID SFP
Port Status
Displays the current status of the port,
as follows:
No_Module
No SFP module is in this
port.
No_Light
Module is not receiving
light.
No_Sync
Module is receiving light
but out of sync.
In_Sync
Module is receiving light
and in sync.
Laser_Flt
Module signaling a laser
fault (defective SFP).
Port_Flt
Port is marked faulty
(defective SFP, cable, or
device).
Diag_Flt
Port failed diagnostics.
Online
Port is up and running.
Lock_Ref
Port is locking to
reference signal.
