Switch View
4–96 Web Tools Version 3.0.x/4.0.x User Guide
Table 4–28 provides a description of the fields on the Switch Settings tab.
Table 4–28: Switch Settings Tab Fields
Name Enter data for the switch name or make a change to the
existing name.
Domain ID Displays or sets switch domain ID. Domain IDs must be
unique within a fabric. The switch must be disabled to
change domain ID.
To change domain ID, enter new domain ID in this field.
Use a number from 1 to 239 for normal operating mode
(FCSW compatible)
Use a number from 0 to 31 for VC encoded address format
mode (backward compatible to StorageWorks Fibre
Channel 8 or 16 series switches).
Use a number from 97 - 127 for Interop mode.
Serial Number Displays the serial number of the switch. (Read only)
(Status) Enabled Select the radio button to enable the switch.
(Status) Disabled Select the radio button to disable the switch.
Extended Fabric
Mode Check the box to allow ports to be configured for long
distance, or uncheck to turn the option off.
OK Select to exit Administrative View after any changes have
been saved.
Apply Select to save any changes made to this tab and remain in
the current tab. Additional changes can be made and the
Apply button clicked when making changes incrementally.
Close Select to exit the Switch Admin view. If changes have been
made and not committed by clicking the Apply button, a
dialog box is presented. It allows the changes to be
committed or deleted.
Reset Select to reset the tab to the last set of committed changes.
If the Apply button has not been pressed on this tab, the
parameters are returned to the original values the tab had
when it was initially displayed.
Refresh Select to receive the latest switch setting information.
