Fabric View
–101 Web Tools Version 3.0.x/4.0.x User Guide 3–101
Member Selection
List This field displays a list of potential zone members,
including switches, ports, WWNs, QuickLoop AL_PAs,
and Fabric Assists.
[Name] Zone
Members This field lists the zone members selected in the Zone
Name pull-down menu. The name on this list depends on
the name of the selected zone member. If a name is not
selected, the name displays as “null Members.”
< Search Mem Click to search for a switch name, WWN, alias, zone,
QuickLoop, or FA Zone in the Member Selection List
based on the type of objects displayed in that list.
Add Mem > Click to add a member from the member selection list
into the Zone Members list.
< Remove Mem Click to remove a member from the Zone Member List
when selected.
Add Device > Click to add a device that currently is not part of the
Fabric.
Ref Zone Click to refresh the local zoning database copied from
the switch. This button automatically flashes red/gray if
the fabric zoning data is changed by another client.
A/D WWN Click to add or delete a WWN to or from all the aliases,
zones, and FA zones defined
Rpl WWN Click to replace a WWN with another one in all aliases,
zones, and FA zones defined.
OK Click to apply the changes to the switch and exit the
switch.
Apply Click to apply the changes to the switch.
Close Click to exit the window without making any changes to
the switch.
Clr All Select to clear the zoning database, disable the effective
configuration (if there is one), and then commit to the
switch.
Table 3–37: AL_PA Device Zone Tab Fields (Continued)
