3–1

Web Tools Version 3.0.x/4.0.x User Guide

3

Fabric View

This chapter describes the views and interfaces available through the Fabric View of
Web Tools, which consist of the following:

Fabric Events View on page 3–7

Fabric Topology View on page 3–9

Name Server Table View on page 3–11

Zone Administration View V3.0.x (Optional Software) on page 3–13

Zone Administration View V4.0.x (Optional Software) on page 3–68

NOTE: Switch/Fabric administration can be accomplished through different methods, such as
through Telnet, SNMP, and the Web, any of which can occur simultaneously.

Fabric View Page

The Fabric View is the first web page that displays when you connect to a switch.The
Fabric View provides access to specific information about each switch, in addition to
other options, and a legend explaining the colors used to indicate switch status.

To launch Web Tools and access Fabric View:

1. Launch the web browser.

2. Enter the switch name or IP address in the Location/Address field and press

Enter.

For example:

http://switch name_or_ip

NOTE: This switch is assumed to be the local domain.

Web Tools launches, displaying Fabric View in detailed view as shown in
Figure 3–1. The Fabric View consists of two logical parts:

Control Panel

Switch Panel
