Port View

5–13

Web Tools Version 3.0.x/4.0.x User Guide

5–13

No_Sync

Module is receiving
light but out of sync.

In_Sync

Module is receiving
light and in sync.

Laser_Flt

Module signaling a
laser fault (defective
SFP).

Port_Flt

Port is marked faulty
(defective SFP, cable,
or device).

Diag_Flt

Port failed diagnostics.

Online

Port is up and running.

Lock_Ref

Port is locking to
reference signal.

NOTE: Removing a cable from an E_Port temporarily generates errors, causing the status
to show as faulty. The status returns to healthy when the sample interval has passed (the
default interval is 1 minute).

Port Type

Displays the port types, as follows:

E_Port

Switch link port

G_Port

Generic port

U_Port

Universal port

F_Port

Fabric port

FL_Port

Fabric loop port

L_Port

Loop port

Table 5–4: Port Information View Fields (Continued)
