4–130

Web Tools Version 3.0.x/4.0.x User Guide

Telnet Interface

Accessing the Telnet Interface

1. Launch the web browser.

2. Enter the switch name or IP address in the Location/Address field and press

Enter.

Example:

http://switch name

Web Tools launches, displaying Fabric View.

3. Click the Telnet icon on the switch panel.

The Telnet Interface displays, as shown in Figure 4–76.

Figure 4–76: The Telnet Interface

Using the Telnet Interface

Up to 14 Telnet sessions can be running simultaneously on a 4.0.x chassis:

•

Four sessions for Root

•

Four sessions for Factory

•

Two sessions for Admin

•

Four sessions for User
