Fabric View

3–102

Web Tools Version 3.0.x/4.0.x User Guide

QuickLoop Tab

Use the QuickLoop tab to create and manage QuickLoops. For information on
managing the QuickLoop feature separately, see the “Loop Tab” on page 5–20 in this
document. The QuickLoop tab is shown in Figure 3–42.

.

Figure 3–42: QuickLoop Tab of the AL_PA Level Zoning menu

Table 3–38 provides a description of the fields on the QuickLoop tab.

Table 3–38: QuickLoop Tab Fields

QuickLoop Name

Select an existing QuickLoop member name to modify.

Create Qloop

Click to create a new QuickLoop member.

Delete Qloop

Click to delete a QuickLoop member.

Rename Qloop

Click to rename a QuickLoop member.
