Fabric View

3–13

Web Tools Version 3.0.x/4.0.x User Guide

3–13

The Name Server Table also includes the columns listed in Table 3–5.

Zone Administration View V3.0.x (Optional Software)

A Zoning license and administrative privileges are required to access this view. If a
switch or device is added or removed from the network, it is necessary to save the
changes and relaunch the Zone Administration view for the changes to take effect.

NOTE: The following section is intended to describe Zoning configurations when using Web
Tools V3.0.x. For specific 4.0.x Zoning information, see “Zone Administration View V4.0.x
(Optional Software)” on page 3–68.
For more detailed information about Zoning, refer to the HP
StorageWorks Zoning Version 3.0.x/4.0.x User Guide
.

Table 3–5: Name Server Table View Additional Columns

Domain #

Displays the domain ID of the switch to which the device is
connected.

Port #

Displays the number of the switch port to which the device
is connected.

Port ID

Displays the port ID of the device (24-bit hexadecimal
value).

Port Type

Displays the port type of the device (N for fabric direct
attached port or NL for fabric direct attached loop port).

Port WWN

Displays the World Wide Name of the device port.

Node WWN

Displays the World Wide Name of the device node.

Symbolic Name

Displays the symbolic name of the device assigned
through the SCSI INQUIRY command.

FC4 Types

Displays the Fibre Channel FC4 layer types supported by
the device, such as IP or FCP.

COS

Displays the Fibre Channel classes of service supported
by the device.

Fabric Port Name

Displays the name of the fabric port in use by the device.

Port IP Address

Displays the IP address of the fabric port.

Hard Address

Displays the hard address of the fabric port.

Member of Zones

Displays the zones to which this device belongs. This
column does not update when the table is refreshed. To
view updated zoning information, close and reopen the
Name Server Table.
