Switch View
–117 Web Tools Version 3.0.x/4.0.x User Guide 4–117
Reset Click to reset the tab to the last set of committed changes. If
the Apply button has not been pressed on this tab, the
parameters are returned to the original values the tab had
when it was initially displayed.
Refresh Click to view the most current configuration information.
Log Area Displays coded messages:
Successful changes to settings are logged in italics.
Error messages are indicated in red.
Warning messages are indicated in orange.
Additional information is indicated in magenta.
QuickHelp Status
bar Displays one-line description about entry fields or tool tip on
any modifiable component. A green icon indicates that a
switch enabled; a red icon is displayed when the switch is
disabled using the Admin tool.
Table 4–37: Configure Tab, Arbitrated Loop Sub-tab Fields
Arbitrated Loop Sub-tab
Send Fan Frames Click that Fabric Access Notification frames be sent to public
loop devices to notify them of their node ID and address.
Always Send
RSCN Click a Remote State Change notification, following the
completion of loop initialization, when FL_Ports detect the
presence of new devices or the absence of preexisting
devices.
Do Not Allow
AL_PA 0x00 Click box to specify that AL_PA value 0x00 is not allowed.
OK Click to save the changes made to the tab and to exit the
view.
Apply Click to save the changes made to this tab and to stay in the
current tab. Additional changes can be made and the Apply
button pressed when making changes incrementally.
Close Click to exit the current view.
Reset Click to reset the tab to the last set of committed changes. If
the Apply button has not been pressed on this tab, the
parameters are returned to the original values the tab had
when it was initially displayed.
Table 4–36: Configure Tab, Virtual Channel Sub-tab Fields (Continued)
