HP StorageWorks 2.32 SAN Switch User Manual
Page 262

4–106
Web Tools Version 3.0.x/4.0.x User Guide
Ok
Select to save the changes made to the tab and to exit the
view.
Apply
Select to save the changes made to this tab and to stay in
the current tab. Additional changes can be made and the
Apply button pressed when making changes
incrementally.
Close
Select to exit the current view.
Reset
Click to reset the tab to the last set of committed changes.
If the Apply button has not been pressed on this tab, the
parameters are returned to the original values the tab had
when it was initially displayed.
Refresh
Click to view the most current SNMP information.
Log Area
Displays coded messages:
•
Successful changes to settings are logged in italics.
•
Error messages are indicated in red.
•
Warning messages are indicated in orange.
•
Additional information is indicated in magenta.
QuickHelp Status
bar
Displays one-line description about entry fields or tool tip
on any modifiable component. A green icon indicates that
a switch enabled; a red icon is displayed when the switch
is disabled using the Admin tool.
Table 4–31: SNMP Tab Fields (Continued)
