Switch View

–121

Web Tools Version 3.0.x/4.0.x User Guide

4–121

Table 4–39 provides a description of the fields on the Routing tab.

Table 4–39: Routing Tab Fields

Dynamic Load
Sharing (DLS)

Click the radio button to turn Dynamic Load Sharing on or
off.

In-Order Delivery
(IOD)

Click the radio button to turn In-Order Delivery on or off.

Port Number

Displays Port Number.

Cost

Use the Cost field to change the link cost for a particular
port.

In Port

Displays In Port number.

Destination
Domain

Displays the destination domain ID for the
“comma-separated” participating static routes for a
particular in port. The destination domain IDs match the out
ports in the cell.

Out Port

Enter the out port. It should be within the range of ports that
are available for static routes for the current domain. More
than one out port can be used for any In port with a
different domain ID. Each domain ID requires an out port.

Slot Number tabs

Click to view a specific slot. Available only when viewing an
StorageWorks Core switch series switch.

OK

Click to save the changes made to the tab and to exit the
tab.

Apply

Click to save the changes made to this tab and to stay in
the current tab. Additional changes can be made and the
Apply button pressed when making changes incrementally.

Close

Click to exit the current tab. If changes have been made but
not committed by clicking the Apply button, a dialog box
displays.

Reset

Click to reset the tab to the last set of committed changes.
If the Apply button has not been pressed on this tab, the
parameters are returned to the original values the tab had
when it was initially displayed.

Refresh

Click to view the most current information available from the
switch.
