Switch View

4–110

Web Tools Version 3.0.x/4.0.x User Guide

Table 4–33 provides a description of the fields on the Report tab.

Table 4–33: Report Tab Fields

List of Switches

Displays a list of switches that form a fabric.

Current Switch
Information

Displays information for the current switch, such as the IP
address and the Ethernet Subnetmask.

List of
Inter-Switch Links

Displays a list of direct physical links that are attached to the
current switch.

List of Blades and
Ports

Displays a list of blades and ports for the current switch.

Name Server

Displays the Name Server information that is available in the
switch. For more information about the Name Server, see
Name Server Table View” on page 3–11.

Zoning

Displays a report of Zoning information for the switch. For
more information regarding Zoning, see “Zone
Administration View V3.0.x (Optional Software)”
on
page 3–13.

SFP Serial ID
Information

Displays SFP information for each port on the switch. For
more information, see “SFP Tab” on page 5–7.

Print Report

Select to print a switch report.

Close

Click to exit the current view.

Refresh

Click to view the most current Report information.

Log Area

Displays coded messages:

Successful changes to settings are logged in italics.

Error messages are indicated in red.

Warning messages are indicated in orange.

Additional information is indicated in magenta.

QuickHelp Status
bar

Displays one-line description about entry fields or tool tip on
any modifiable component. A green icon indicates that a
switch enabled; a red icon is displayed when the switch is
disabled using the Admin tool.
