If you configure buffers at the port or queue level (using qd commands or buffer profiles), the buffer
sharing level automatically changes to 1. You can change it manually.

FCX buffer sharing level definitions

TABLE 13

Buffer sharing level

Shared buffer limit (in buffers)

Shared buffer total (in kilobytes)

1

256

64

2

1024

250

3

1536

375

4

2048

500

5 (default)

2560

625

6

3072

750

7

3584

875

8

4096

1000

ICX 6610 buffer sharing levels

The ICX 6610 buffer sharing level configures the shared buffers on the device. The ICX 6610 shared
buffers are divided into pools. Each of the following pools defines the buffer allocation for a set of
traffic class (TC) queues:

• Pool 0 contains TCs 0 and 1.
• Pool 1 contains TCs 2, 3, and 4.
• Pool 2 contains TCs 5 and 6.
• Pool 3 contains TC 7.

For example, the buffers allocated to Pool 0 are shared between TCs 0 and 1. The following table
defines the ICX 6610 buffer sharing level settings. Note that only the values of Pool 0 change. For
information about configuring buffer sharing, refer to

Configuring buffer sharing on FCX and ICX

devices

on page 57.

ICX 6610 buffer sharing level definitions

TABLE 14

Buffer sharing level Shared buffer limit

Shared buffer total (in
kilobytes)

Pool 0 sharing buffers
(in kilobytes)

Pool 0 -TC 0, 1

Pool 1 -

TC 2, 3, 4

Pool 2 -

TC 5, 6

Pool 3 -

TC 7

1

Not supported

2

128

128

192

192 250

64

3

256

128

192

192 375

125

4

512

128

192

192 500

250
