NOTE
This feature applies only to Layer 3 Switches.
NOTE
Before using the method described in this section, refer to
VLAN groups and virtual routing interface
on page 394. You might be able to achieve the results you want using the methods in that
section instead.
The following figure shows an example of this type of configuration.
FIGURE 85 Multiple port-based VLANs with separate protocol addresses
As shown in this example, each VLAN has a separate IP subnet address. If you need to conserve IP
subnet addresses, you can configure multiple VLANs with the same IP subnet address, as shown in the
following figure.
VLANs
FastIron Ethernet Switch Platform and Layer 2 Switching Configuration Guide
391
53-1003086-04
