device-B(config-vlan-ipx-proto)# exclude e1 to 4
device-B(config-vlan-other-proto)# vlan 3 name IP-Sub_IPX-Net_VLANs
device-B(config-vlan-3)# untagged e9 to 16
device-B(config-vlan-3)# tagged e25 to 26
device-B(config-vlan-3)# spanning-tree
device-B(config-vlan-3)# spanning-tree priority 500
device-B(config-vlan-3)# ip-sub 10.1.1.0/24 name Green
device-B(config-vlan-ip-subnet)# no dynamic
device-B(config-vlan-ip-subnet)# static e9 to 12 e25 to 26
device-B(config-vlan-ip-subnet)# exclude e13 to 16
device-B(config-vlan-ip-subnet)# ipx-net 1 ethernet_802.3 name Brown
device-B(config-vlan-ipx-network)# no dynamic
device-B(config-vlan-ipx-network)# static e13 to 16 e25 to 26
device-B(config-vlan-ipx-network)# exclude e9 to 12
device-B(config-vlan-ipx-network)# vlan 4 name Purple_ALL-Protocols
device-B(config-vlan-4)# untagged e17 to 24
device-B(config-vlan-4)# tagged e25 to 26
device-B(config-vlan-4)# spanning-tree
Configuring Layer 3 VLANs on FSX-C
Enter the following commands to configure FSX-C.
device# config t
device(config)# host device-C
device-C(config)# vlan 2 name IP_IPX_Protocol
device-C(config-vlan-2)# untagged e1 to 8
device-C(config-vlan-2)# tagged e25 to 26
device-C(config-vlan-2)# spanning-tree
device-C(config-vlan-2)# ip-proto name Red
device-C(config-vlan-ip-proto)# no dynamic
device-C(config-vlan-ip-proto)# static e1 to 4 e25 to 26
device-C(config-vlan-ip-proto)# exclude e5 to 8
device-C(config-vlan-ip-proto)# ipx-proto name Blue
device-C(config-vlan-ipx-proto)# no dynamic
device-C(config-vlan-ipx-proto)# static e5 to 8 e25 to 26
device-C(config-vlan-ipx-proto)# exclude e1 to 4
device-C(config-vlan-other-proto)# vlan 3 name IP-Sub_IPX-Net_VLANs
device-C(config-vlan-3)# untagged e9 to 16
device-C(config-vlan-3)# tagged e25 to 26
device-C(config-vlan-3)# spanning-tree
device-C(config-vlan-3)# ip-sub 10.1.1.0/24 name Green
device-C(config-vlan-ip-subnet)# no dynamic
device-C(config-vlan-ip-subnet)# static e9 to 12 e25 to 26
device-C(config-vlan-ip-subnet)# exclude e13 to 16
device-C(config-vlan-ip-subnet)# ipx-net 1 ethernet_802.3 name Brown
device-C(config-vlan-ipx-network)# no dynamic
device-C(config-vlan-ipx-network)# static e13 to 16 e25 to 26
device-C(config-vlan-ipx-network)# exclude e9 to 12
device-C(config-vlan-ipx-network)# vlan 4 name Purple_ALL-Protocols
device-C(config-vlan-4)# untagged e17 to 24
device-C(config-vlan-4)# tagged e25 to 26
device-C(config-vlan-4)# spanning-tree
IPv6 protocol VLAN configuration
You can configure a protocol-based VLAN as a broadcast domain for IPv6 traffic. When the Layer 3
Switch receives an IPv6 multicast packet (a packet with 06 in the version field and 0xFF as the
beginning of the destination address), the Layer 3 Switch forwards the packet to all other ports.
NOTE
The Layer 3 Switch forwards all IPv6 multicast packets to all ports except the port that received the
packet, and does not distinguish among subnet directed multicasts.
Configuring Layer 3 VLANs on FSX-C
