that port. Since the above configuration consists of a statically configured active port, the active port
pre-empts other ports in the protected link group. Refer to

About active ports

on page 127.

Syntax: [no] protected-link-group group-ID ethernet port to port

The group-ID parameter specifies the protected link group number. Enter a number from 1 - 32.

Syntax: [no] protected-link-group group-ID active-port ethernet port

The group-ID parameter specifies the protected link group number. Enter a number from 1 - 32.

Viewing information about protected link groups

You can use the following show commands to view information about protected link groups:

show protected-link-group
show interface brief
show interface

The following shows example output for the show protected-link-group command.

device#show protected-link-group

Group ID: 1

Member Port(s): ethe 1 to 7

Configured Active Port: 7

Current Active Port: 7

Standby Port(s): ethe 5

Total Number of Protected Link Groups: 1

Syntax: show protected-link-group [ group-ID ]

CLI display of protected link group information

TABLE 26

Field

Description

Group ID

The ID number of the protected link group.

Member Port(s)

The ports that are members of the protected link group.

Configured Active Port The statically configured active port. If you do not statically configure an active port, this

value will be "None".

Current Active Port

The current active port for the protected link group. If all member ports are down, this
value will be "None".

Standby Port(s)

The member ports that are on standby.

The show interface brief command also displays information about protected link groups.

device#show int brief e 3 to 4

Port Link State Dupl Speed Trunk Tag Priori MAC Name

3 Up Inactive Full Auto None Yes level0 0000.00a8.7140

4 Up Forward Full 1G None Yes level0 0000.00a8.7140

In the above output, the State of port 3 is Inactive , which means port 3 is an inactive port in a
protected link group. For active ports in a protected link group, the State will be Active.

Syntax: show interface brief ethernet port

The show interface command also displays information about protected link groups.

device#show int e 3

GigabitEthernet3 is up, line protocol is up, link keepalive is enabled

Port up for 60 seconds

Hardware is GigabitEthernet, address is 0000.00a8.7140 (bia 0000.00a8.7142)

Configured speed auto, actual 1Gbit, configured duplex fdx, actual fdx
