CLI display of STP information (Continued)
TABLE 46
Field
Description
Priority Hex
This device or VLAN STP priority. The value is shown in hexadecimal format.
NOTE
If you configure this value, specify it in decimal format. Refer to
on page 256.
Max age sec
The number of seconds this device or VLAN waits for a configuration BPDU from the root
bridge before deciding the root has become unavailable and performing a reconvergence.
Hello sec
The interval between each configuration BPDU sent by the root bridge.
Hold sec
The minimum number of seconds that must elapse between transmissions of consecutive
Configuration BPDUs on a port.
Fwd dly sec
The number of seconds this device or VLAN waits following a topology change and
consequent reconvergence.
Last Chang sec
The number of seconds since the last time a topology change occurred.
Chg cnt
The number of times the topology has changed since this device was reloaded.
Bridge Address
The STP address of this device or VLAN.
NOTE
If this address is the same as the Root ID, then this device or VLAN is the root bridge for its
spanning tree.
Port STP parameters
Port Num
The port number.
Priority Hex
The port STP priority, in hexadecimal format.
NOTE
If you configure this value, specify it in decimal format. Refer to
on page 257.
Path Cost
The port STP path cost.
Spanning Tree Protocol
