when bgp enabled :

bgp local pref.:100 bgp keep alive:60 sec bgp hold:180 sec

bgp metric:10 bgp local as:1 bgp cluster id:0

bgp ext. distance:20 bgp int. distance:200 bgp local distance:200

System Parameters Default Maximum Current

ip-arp 6000 64000 64000

ip-static-arp 512 6000 6000

multicast-route 64 8192 8192

dvmrp-route 2048 32000 32000

dvmrp-mcache 512 4096 4096

pim-mcache 1024 4096 4096

igmp-max-group-addr 4096 8192 8192

ip-cache 10000 32768 32768

ip-filter-port 1015 1015 1015

ip-filter-sys 2048 8192 4096

l3-vlan 32 1024 1024

ip-qos-session 1024 16000 16000

mac 16384 32768 32768

ip-route 262144 524288 524288

ip-static-route 64 2048 2048

vlan 64 4095 4095

spanning-tree 32 255 255

mac-filter-port 16 256 256

mac-filter-sys 32 512 512

ip-subnet-port 24 128 128

session-limit 65536 160000 65537

view 10 65535 65535

virtual-interface 255 512 512

hw-ip-next-hop 2048 6144 2481

hw-traffic-condition 50 1024 52

rmon-entries 2048 32768 32768

mld-max-group-addr 8192 32768 32768

igmp-snoop-mcache 512 8192 8192

mld-snoop-mcache 512 8192 8192

ip6-route 32768 65536 65536

ip6-static-route 64 512 512

ip6-cache 65536 131072 131072

msdp-sa-cache 4096 8192 8192

gre-tunnels 16 64 64

The following table defines the system parameters in the show default values command output.

System parameters in show default values command

TABLE 5

Parameter

Definition

dvmrp-mcache

PIM and DVMRP multicast cache flows stored in CAM

dvmrp-route

DVMRP routes

hw-ip-mcast-mll

Multicast output interfaces (clients)

hw-ip-next-hop

IP next hops and routes, including unicast next hops and multicast route entries

hw-logical-interface

Hardware logical interface pairs (physical port and VLAN pairs)

hw-traffic-conditioner

Traffic policies

ip-arp

ARP entries

ip-cache

IP forwarding cache entries

ip-filter-port

IP ACL entries per port

ip-filter-sys

IP ACL entries per system

ip-qos-session

Layer 4 session table entries

Basic Layer 2 Features

FastIron Ethernet Switch Platform and Layer 2 Switching Configuration Guide

41

53-1003086-04
