interface l2-tunnel
Creates a Layer 2 tunnel interface.
Syntax interface l2-tunnel tunnel-id
no interface l2-tunnel tunnel-id
Command Default The Layer 2 tunnel interface is not configured by default.
Parameters tunnel-id
Specifies the tunnel ID for the Layer 2 tunnel interface.
Modes Global configuration mode
Usage Guidelines Use this command to configure a Layer 2 tunnel interface and enter interface configuration mode. Only
eight tunnels can be configured. The no form of the command deletes the configuration.
You do not need to configure an IP address for the configured tunnel interface because it is a Layer 2
interface.
Examples The following example creates the Layer 2 tunnel interface 1:
device(config)# interface l2-tunnel 1
The details of the Layer 2 tunnel interface 1 are displayed in the show interface brief command output.
device# show interface brief
Port Link State Dupl Speed Trunk Tag Pvid Pri MAC Name
1/1/1 Down None None None None No 1 0 cc4e.2438.8080
1/1/2 Down None None None None No 1 0 cc4e.2438.8081
1/1/3 Disable None None None 6 Yes N/A 0 cc4e.2438.8080
1/1/4 Down None None None None No 1 0 cc4e.2438.8083
1/1/5 Up Forward Full 1G 10 Yes N/A 0 cc4e.2438.8080 VXL1
mgmt1 Up None Full 1G None No None 0 cc4e.2438.8080
Port Link State Dupl Speed Trunk Tag Pvid Pri MAC Name
ve151 Down N/A N/A N/A None N/A N/A N/A cc4e.2438.8080 toMLX
ve161 Down N/A N/A N/A None N/A N/A N/A cc4e.2438.8080 toMLX_vrf_
ve175 Down N/A N/A N/A None N/A N/A N/A cc4e.2438.8080 bgp-vrf-11
ve181 Up N/A N/A N/A None N/A N/A N/A cc4e.2438.8080 toCER
ve191 Up N/A N/A N/A None N/A N/A N/A cc4e.2438.8080 toCER_vrf_
ve205 Up N/A N/A N/A None N/A N/A N/A cc4e.2438.8080 bgp-vrf-11
Port Link State Dupl Speed Trunk Tag Pvid Pri MAC Name
lb1 Up N/A N/A N/A None N/A N/A N/A N/A for-router
lb3 Up N/A N/A N/A None N/A N/A N/A N/A for-mcast
lb11 Up N/A N/A N/A None N/A N/A N/A N/A for-router
Port Link State Dupl Speed Trunk Tag Pvid Pri MAC Name
l2-tn1 Up N/A N/A N/A None N/A N/A N/A N/A
l2-tn2 Down N/A N/A N/A None N/A N/A N/A N/A
l2-tn10 Down N/A N/A N/A None N/A N/A N/A N/A
History
Release version Command history
08.0.10d This command was introduced.
interface l2-tunnel
