ports ethe 1/17 to 1/19
primary-port 1/17
deploy
!
lag lag_agg_b_3 dynamic id 104
ports ethe 1/21 to 1/23
primary-port 1/21
deploy
!
vlan 2 name session-vlan by port
tagged ethe 2/1 to 2/2
router-interface ve 2
!
vlan 3 by port
tagged ethe 1/11
router-interface ve 3
!
!
vlan 1905 by port
tagged ethe 1/17 to 1/19 ethe 1/21 to 1/23 ethe 2/1 to 2/2
!
hostname R2
!
interface ve 2
ip address 10.1.1.2 255.255.255.0
!
interface ve 3
ip address 10.1.2.2 255.255.255.0
!
cluster MCT1 1
rbridge-id 2
session-vlan 2
keep-alive-vlan 3
icl BH1 ethernet 2/1
peer 10.1.1.1 rbridge-id 1 icl BH1
deploy
client client-1
rbridge-id 1901
client-interface ethe 1/21
deploy
client client-2
rbridge-id 1902
client-interface ethe 1/17
!
Two-level MCT example
The following figure depicts a two-level MCT configuration. The clients can be server hosts or
networking devices. The associated configuration follows.
NOTE
The LAG IDs are locally significant only and need not be matching on the two ends of a LAG.
