VSRP parameters (Continued)

TABLE 21

Parameter

Description

Default

For more
information

Timer scale

The value used by the software to calculate all
VSRP timers. Increasing the timer scale value
decreases the length of all the VSRP timers
equally, without changing the ratio of one timer to
another.

1

Changing the timer
scale

on page 105

Interface parameters

Authentication
type

The type of authentication the VSRP devices use
to validate VSRP packets. On Layer 3 Switches,
the authentication type must match the
authentication type the VRID port uses with other
routing protocols such as OSPF.

• No authentication - The interfaces do not use

authentication.

• Simple - The interface uses a simple text-string

as a password in packets sent on the interface.
If the interface uses simple password
authentication, the VRID configured on the
interface must use the same authentication
type and the same password.

NOTE
MD5 is not supported.

No
authentication

Configuring
authentication

on

page 106

VSRP-Aware Security Parameters

VSRP-Aware
Authentication
type

The type of authentication the VSRP-aware
devices will use on a VSRP backup switch:

• No authentication - The device does not accept

incoming packets that have authentication
strings.

• Simple - The device uses a simple text-string

as the authentication string for accepting
incoming packets.

Not configured

Configuring security
features on a VSRP-
aware device

on

page 106

VRID parameters

VSRP device type Whether the device is a VSRP Backup for the

VRID.

All VSRP devices for a given VRID are Backups.

Not configured

Configuring basic
VSRP parameters

on

page 104

VSRP ports

The ports in the VRID VLAN that you want to use
as VRID interfaces. You can selectively exclude
individual ports from VSRP while allowing them to
remain in the VLAN.

All ports in the
VRID VLAN

Removing a port from
the VRID VLAN

on

page 107

Metro Features
