Displaying VSRP information

You can display the following VSRP information:

• Configuration information and current parameter values for a VRID or VLAN
• The interfaces on a VSRP-aware device that are active for the VRID

Displaying VRID information

To display VSRP information, enter the following command.

device#show vsrp vrid 1

Total number of VSRP routers defined: 2

VLAN 200

auth-type no authentication

VRID 1

State Administrative-status Advertise-backup Preempt-mode save-current

standby enabled disabled true false

Parameter Configured Current Unit

priority 100 80 (100-0)*(4.0/5.0)

hello-interval 1 1 sec/1

dead-interval 3 3 sec/1

hold-interval 3 3 sec/1

initial-ttl 2 2 hops

next hello sent in 00:00:00.8

Member ports: ethe 1/1 to 1/5

Operational ports: ethe 1/1 to 1/4

Forwarding ports: ethe 1/1 to 1/4

Syntax: show vsrp [ vrid num | vlan vlan-id ]

This display shows the following information when you use the vrid num or vlan vlan-id parameter. For
information about the display when you use the aware parameter, refer to

Displaying the active

interfaces for a VRID

on page 116.

CLI display of VSRP VRID or VLAN information

TABLE 22

Field

Description

Total number of VSRP
routers defined

The total number of VRIDs configured on this device.

VLAN

The VLAN on which VSRP is configured.

auth-type

The authentication type in effect on the ports in the VSRP VLAN.

VRID parameters

VRID

The VRID for which the following information is displayed.

Displaying VSRP information
