Displaying state machine information
Use the show cluster client command to display additional state machine information, including the
reason a local CCEP has gone down. You can specify an individual cluster and client as an option.
device# show cluster 1 client
Cluster 1 1
===================
Rbridge Id: 101, Session Vlan: 3999, Keep-Alive Vlan: 4001
Cluster State: Deploy
Client Isolation Mode: Loose
Configured Member Vlan Range: 100 to 105
Active Member Vlan Range: 100 to 105
MCT Peer's Reachability status using Keep-Alive Vlan: Peer Reachable
Client Info:
------------
Client: c1, rbridge-id: 300, Deployed
Client Port: 3/11
State: Up
Number of times Local CCEP down: 0
Number of times Remote CCEP down: 0
Number of times Remote Client undeployed: 0
Total CCRR packets sent: 4
Total CCRR packets received: 3
Syntax: show cluster cluster_name/cluster_id client [client_name/client_RbridgeID ]
The following table shows the messages that may be displayed to explain why the local CCEP is down.
Reasons for Local CCEP down
TABLE 33
Reason for Local CCEP down
Meaning
client-interfaces shutdown
Command is configured.
client-isolation strict
Command is configured.
Deploy mismatch
Client is not deployed remotely.
Slave state
Client is in slave state when CCP is down.
cluster and client undeployed
Neither the cluster nor client is deployed.
cluster undeployed
Cluster is not deployed.
client undeployed
Client is not deployed.
Displaying cluster, peer, and client states
Use the show cluster ccp peer command to display cluster, peer device, and client states. As an
option, you can specify an individual cluster and request additional details.
device# show cluster 1 ccp peer
...
PEER IP ADDRESS STATE UP TIME
--------------- ------------- --------------
10.1.1.1 OPERATIONAL 0 days: 2 hr:25 min:16 sec
device (config-cluster-SX_1)# show cluster 1 ccp peer detail
**************Peer Session Details*********************
IP address of the peer 10.1.1.1
