CLI display of VSRP VRID or VLAN information (Continued)

TABLE 22

Field

Description

state

This device VSRP state for the VRID. The state can be one of the following:

• initialize - The VRID is not enabled (activated). If the state remains "initialize" after

you activate the VRID, make sure that the VRID is also configured on the other
routers and that the routers can communicate with each other.

NOTE
If the state is "initialize" and the mode is incomplete, make sure you have specified
the IP address for the VRID.

• standby - This device is a Backup for the VRID.
• master - This device is the Master for the VRID.

Administrative-status

The administrative status of the VRID. The administrative status can be one of the
following:

• disabled - The VRID is configured on the interface but VSRP or VRRP-E has not

been activated on the interface.

• enabled - VSRP has been activated on the interface.

Advertise-backup

Whether the device is enabled to send VSRP Hello messages when it is a Backup.
This field can have one of the following values:

• disabled - The device does not send Hello messages when it is a Backup.
• enabled - The device does send Hello messages when it is a Backup.

Preempt-mode

Whether the device can be pre-empted by a device with a higher VSRP priority after
this device becomes the Master. This field can have one of the following values:

• disabled - The device cannot be pre-empted.
• enabled - The device can be pre-empted.

save-current

The source of VSRP timer values preferred when you save the configuration. This
field can have one of the following values:

• false - The timer values configured on this device are saved.
• true - The timer values most recently received from the Master are saved instead

of the locally configured values.

NOTE
For the following fields:

• Configured - indicates the parameter value configured on this device.
• Current - indicates the parameter value received from the Master.
• Unit - indicates the formula used tor calculating the VSRP priority and the timer scales in effect for the VSRP

timers. A timer true value is the value listed in the Configured or Current field divided by the scale value.
