If a single multi-range VLAN command contains more than 64 VLANs, the CLI does not add the VLAN
IDs but instead displays an error message. An example is given below.

device(config)#vlan 100 to 356

ERROR -can't have more than 64 vlans at a time in a multi-range vlan command

Configuring a multi-range VLAN

You can configure multiple VLANs with a single command from the multi-range VLAN configuration
level. For example, if you want to add tagged ethernet port 1/1/1 in the VLAN 16 17 20 21 22 23 24,
enter the following commands.

device(config)#vlan 16 17 20 to 24

device(config-mvlan-16*24)#tag e 1/1/1

device(config-mvlan-16*24)#

The first command will take you to the multi-range VLAN configuration mode. The second command
will add tagged ethernet port 1/1/1 in the specified VLANs, VLAN 16 17 20 21 22 23 and 24.

The following VLAN parameters can be configured with the specified VLAN range.

Command

Explanation

atalk-proto

Set AppleTalk protocol VLAN

clear

Clear table/statistics/keys

decnet-proto

Set decnet protocol VLAN

end

End Configuration level and goto Privileged level

exit

Exit current level

ip-proto

Set IP protocol VLAN

ipv6-proto

Set IPv6 protocol VLAN

ipx-proto

Set IPX protocol VLAN

mac-vlan-permit

Define port to be used for MAC Based VLan

monitor

Monitor Ingress Traffic on this VLAN(Enable VLAN

multicast

IGMP snooping on this VLAN Mirroring)

netbios-proto

Set netbios protocol VLAN

no

Undo/disable commands

other-proto

Set other protocol VLAN

quit

Exit to User level

show

Show system information

VLANs
