These commands create a port-based VLAN on chassis ports 1/1 - 1/6 named "Mktg-LAN", configure
an IP subnet VLAN within the port-based VLAN, and then add ports from the port-based VLAN
dynamically.

Syntax: vlan vlan-id name string [ by port ]

Syntax: untagged ethernet [slotnum/]portnum to [slotnum/]portnum

or

Syntax: untagged ethernet [slotnum/]portnum ethernet [slotnum/]portnum

NOTE
Use the first untagged command for adding a range of ports. Use the second command for adding
separate ports (not in a range).

Syntax: ip-subnet ip-addr ip-mask[ name string]

or

Syntax: ip-subnet ip-addr/mask-bits [ name string]

Syntax: dynamic

Configuring an IPX network VLAN with dynamic ports

To configure port-based VLAN 20, then configure an IPX network VLAN within the port-based VLAN
with dynamic ports, enter commands such as the following.

device(config)# vlan 20 name IPX_VLAN by port

device(config-vlan-10)# untagged ethernet 2/1 to 2/6

added untagged port ethe 2/1 to 2/6 to port-vlan 20.

device(config-vlan-10)# ipx-network abcd ethernet_ii name Eng-LAN

device(config-vlan-ipx-network)# dynamic

device(config)# write memory

These commands create a port-based VLAN on chassis ports 2/1 - 2/6 named "Eng-LAN", configure an
IPX network VLAN within the port-based VLAN, and then add ports from the port-based VLAN
dynamically.

Syntax: vlan vlan-id name string [ by port ]

Syntax: untagged ethernet [slotnum/]portnum to [slotnum/]portnum

or

Syntax: untagged ethernet [slotnum/]portnum ethernet [slotnum/]portnum

NOTE
Use the first untagged command for adding a range of ports. Use the second command for adding
separate ports (not in a range).

Syntax: ipx-network network-addr ethernet_ii|ethernet_802.2 | ethernet_802.3 | ethernet_snap
[name string]

Syntax: dynamic

Configuring an IPX network VLAN with dynamic ports
