CLI display of GVRP statistics (Continued)

TABLE 38

Field

Description

Join Empty Received

The number of Join Empty messages received.

Join In Received

The number of Join In messages received.

Leave Empty Received

The number of Leave Empty messages received.

Leave In Received

The number of Leave In messages received.

Empty Received

The number of Empty messages received.

Leave All Transmitted

The number of Leaveall messages sent.

Join Empty Transmitted

The number of Join Empty messages sent.

Join In Transmitted

The number of Join In messages sent.

Leave Empty Transmitted

The number of Leave Empty messages sent.

Leave In Transmitted

The number of Leave In messages sent.

Empty Transmitted

The number of Empty messages sent.

Invalid Messages/Attributes
Skipped

The number of invalid messages or attributes received or skipped. This can occur
in the following cases:

• The incoming GVRP PDU has an incorrect length.
• "End of PDU" was reached before the complete attribute could be parsed.
• The Attribute Type of the attribute that was being parsed was not the GVRP

VID Attribute Type (0x01).

• The attribute that was being parsed had an invalid attribute length.
• The attribute that was being parsed had an invalid GARP event.
• The attribute that was being parsed had an invalid VLAN ID. The valid range is

1 - 4095.

Failed Registrations

The number of failed registrations that have occurred. A failed registration can
occur for the following reasons:

• Join requests were received on a port that was blocked from learning dynamic

VLANs (GVRP Blocking state).

• An entry for a new GVRP VLAN could not be created in the GVRP database.

To display GVRP statistics for all ports, enter the show gvrp statistics all command.
