NOTE
When multiple ports from the same server are connected to an ICX 6650, the port on the ICX 6650
connected to the PXE-capable port on the server is the port that must be configured to the force-up
state. The PXE-capable port varies from server to server.

Keep the following points in mind when configuring a port to a force-up state:

• A port can only be configured as the force-up port before the client is deployed.
• Only one port in an LACP link aggregation group can be configured as the force-up port. If you

configure multiple ports as force-up, this error message is displayed: Error: port portno is
already configured as force-up port.

• When a port is configured for force-up and the server boots for the first time, the port does not wait

for any LACPDU but immediately begin to forward packets.

• If the port receives an LACPDU, it bundles with other ports and forms a link aggregation group. The

server is operational.

• If the force-up port goes down while in a link aggregation group, the port continues to perform as a

normal LACP trunk, and the server remains operational, with some ports down.

• If the force-up port stops receiving LACPDU, the port ignores the time-out and remains operational.

To configure the LACP client in a force-up state, use the client-interface link-aggregation force-
up ethernet
command at the Client level.

Syntax: [no] client-interface link-aggregation force-up ethernet unit/
slotnum/portnum

The following example shows the link aggregation information for a port
configured to a force-up state.

ICX6650-64 Router# show lag id 163

Total number of LAGs: 11

Total number of deployed LAGs: 11

Total number of trunks created:11 (113 available)

LACP System Priority / ID: 1 / 748e.f88f.2222

LACP Long timeout: 120, default: 120

LACP Short timeout: 3, default: 3

=== LAG "CCEP-163" ID 163 (dynamic Deployed) ===

LAG Configuration:

Ports: e 1/1/47 to 1/1/48

Port Count: 2

Primary Port: 1/1/47

Trunk Type: hash-based

LACP Key: 20163

Deployment: HW Trunk ID 3

This is a Multi Chassis Trunk: (System Id: 0180.c200.0001, Key: 30163)

Port Link State Dupl Speed Trunk Tag Pvid Pri MAC Name

1/1/47 Up Forward Full 1G 163 Yes N/A 0 748e.f88f.2222

1/1/48 Down None None None 163 Yes N/A 0 748e.f88f.2222

Port [Sys P] [Port P] [ Key ] [Act][Tio][Agg][Syn][Col][Dis][Def][Exp][Ope]

1/1/47 1 1 20163 Yes L Agg Syn Col Dis Def No Frc

1/1/48 1 1 20163 Yes L Agg Syn No No Def No Dwn

Partner Info and PDU Statistics

Port Partner Partner LACP LACP

System MAC Key Rx Count Tx Count

1/1/47 0000.0000.0000 46 5475 5558

1/1/48 0000.0000.0000 47 5477 5487

Multi-Chassis Trunking
