User’s Manual of WGS3-24000 / WGS3-24240
350
4.7.6.5 PIM-SM Component Summary
Figure 4-6-82 PIM-SM Component Summary
Non-Configurable Data
Object Description
• Component Index Unique number identifying the component index.
• Component BSR
Address
Displays the IP address of the bootstrap router (BSR) for the local PIM region.
• Component BSR
Expiry Time
Displays the minimum time remaining before the bootstrap router in the local
domain will be declared.
• Component CRP Hold
Time
The hold time of the component when it is a candidate Rendezvous Point in the
local domain.
• Refresh button Refresh the data on the screen with the present state of the data in the router.
