User’s Manual of WGS3-24000 / WGS3-24240
326
• Total Number of
Routes
The number of routes in the DVMRP routing table.
• Reachable Routes
The number of routes in the DVMRP routing table that have a non-infinite metric.
• Submit button
Send the updated configuration to the switch. Configuration changes take effect
immediately. These changes will not be retained across a power cycle unless a
save is performed.
#
Note
:
Only one multicast routing protocol could be enabled at one time. That means, for example, once
the PIM-DM admin mode is enabled, the user is not able to enable the DVMRP.
4.7.3.2 DVMRP Interface Configuration
Figure 4-6-63 DVMRP Interface Configuation
Selection Criteria
Object
Description
• Slot/Port
Select the interface for which data is to be configured. You must configure at
least one router interface before you configure a DVMRP interface. Otherwise
you will see a message telling you that no router interfaces are available, and the
configuration screen will not be displayed.
Configurable Data
Object
Description
• Interface Mode
Select enable or disable from the pulldown menu to set the administrative mode
of the selected DVMRP routing interface.
