Chapter 4 Parameters|
Revision June 2008, 04EE, SW--PW V1.11/CTL V2.11 4-37
4.3 Description of Parameter Settings
Group 0: User Parameters This parameter can be set during operation.
00.00 Identity Code of the AC Motor Drive
Settings Read Only Factory setting: ##
00.01 Rated Current Display of the AC Motor Drive
Settings Read Only Factory setting: #.#
Pr. 00.00 displays the identity code of the AC motor drive. The capacity, rated current, rated
voltage and the max. carrier frequency relate to the identity code. Users can use the following
table to check how the rated current, rated voltage and max. carrier frequency of the AC motor
drive correspond to the identity code.
Pr.00.01 displays the rated current of the AC motor drive. By reading this parameter the user
can check if the AC motor drive is correct.
115V/230V Series
kW 0.2 0.4 0.75 1.5 2.2 3.7 5.5 7.5
HP 0.25 0.5 1.0 2.0 3.0 5.0 7.5 10
Pr.00-00 0 2 4 6 8 10 12 14
Rated Output
Current (A)
1.6 2.5 4.2 7.5 11.0 17 25 33
Max. Carrier
Frequency
15kHz
460V Series
kW 0.4 0.75 1.5 2.2 3.7 5.5 7.5 11
HP 0.5 1.0 2.0 3.0 5.0 7.5 10 15
Pr.00-00 3 5 7 9 11 13 15 17
Rated Output
Current (A)
1.5 2.5 4.2 5.5 8.5 13 18 24
Max. Carrier
Frequency
15kHz
00.02 Parameter Reset
Factory Setting: 0
Settings 0 Parameter can be read/written
1 All parameters are read-only
6 Clear PLC program (NOT for VFD*E*C models)
9 All parameters are reset to factory settings (50Hz, 230V/400V or
220V/380V depends on Pr.00.12)
10 All parameters are reset to factory settings (60Hz, 115V/220V/440V)
