Delta Electronics AC Motor Drive VFD-E - Manual (Page 79)

Chapter 4 Parameters|
4-26 Revision June 2008, 04EE, SW--PW V1.11/CTL V2.11
Parameter Explanation Settings
Factory
Setting
Customer
10.02
Proportional Gain
(P)
0.0 to 10.0 1.0
10.03 Integral Time (I) 0.00 to 100.0 sec (0.00=disable) 1.00
10.04
Derivative Control
(D) 0.00 to 1.00 sec
0.00
10.05
Upper Bound for
Integral Control
0 to 100% 100
10.06
Primary Delay Filter
Time
0.0 to 2.5 sec 0.0
10.07
PID Output Freq
Limit
0 to 110% 100
10.08
PID Feedback
Signal Detection
Time
0.0 to 3600 sec (0.0 disable) 60.0
0: Warn and RAMP to stop
1: Warn and COAST to stop 10.09
Treatment of the
Erroneous PID
Feedback Signals
2: Warn and keep operation
0
10.10
Gain Over the PID
Detection Value
0.0 to 10.0 1.0
10.11
Source of PID Set
point 0.00 to 600.0Hz
0.00
10.12 PID Offset Level 1.0 to 50.0% 10.0
10.13
Detection Time of
PID Offset
0.1 to 300.0 sec 5.0
10.14
Sleep/Wake Up
Detection Time
0.0 to 6550 sec 0.0
10.15 Sleep Frequency 0.00 to 600.0 Hz 0.00
10.16 Wakeup Frequency 0.00 to 600.0 Hz 0.00
0: By PID control
10.17
Minimum PID
Output Frequency
Selection
1: By minimum output frequency (Pr.01.05)
0
Group 11 Parameters for Extension Card
