Delta Electronics AC Motor Drive VFD-E User Manual
Page 89
Chapter 4 Parameters|
4-36
Revision June 2008, 04EE, SW--PW V1.11/CTL V2.11
Output Signal for Base Block
Applications Purpose
Functions
Related
Parameters
General application
Provide a signal for
running status
When executing Base Block, a signal
is given for external system or control
wiring.
03.00~03.01
Overheat Warning for Heat Sink
Applications Purpose
Functions
Related
Parameters
General application
For safety
When heat sink is overheated, it will
send a signal for external system or
control wiring.
03.00~03.01
Multi-function Analog Output
Applications Purpose
Functions
Related
Parameters
General application
Display running
status
The value of frequency, output
current/voltage can be read by
connecting a frequency meter or
voltage/current meter.
03.06
