Delta Electronics AC Motor Drive VFD-E User Manual
Page 319
Appendix D How to Use PLC Function|
D-36
Revision June 2008, 04EE, SW--PW V1.11/CTL V2.11
Mnemonic Function
INV Inverting
Operation
Operand None
Explanations:
Inverting the operation result and use the new data as an operation result.
Program Example:
Ladder diagram:
Command code: Operation:
LD
X0
Load A contact of X0
INV
Inverting the operation result
X0
Y1
OUT
Y1
Drive Y1 coil
Mnemonic Function
OUT Output
coil
X0~X17 Y0~Y17
M0~M159 T0~15 C0~C7 D0~D29
Operand
--
9
9
-- -- --
Explanations:
Output the logic calculation result before the OUT command to specific device.
Motion of coil contact
OUT command
Contact
Operation
result
Coil
A contact (normally open)
B contact (normally closed)
FALSE OFF Non-continuity
Continuity
TRUE ON Continuity
Non-continuity
