Delta Electronics AC Motor Drive VFD-E User Manual
Page 154

Chapter 4 Parameters|
Revision June 2008, 04EE, SW--PW V1.11/CTL V2.11
4-101
If temperature exceeds the motor PTC overheat warning level (Pr.07.15), the drive will act
according to Pr.07.17 and display
. If the temperature decreases below the result
(Pr.07.15 minus Pr.07.16), the warning display will disappear.
07.13
Input Debouncing Time of the PTC Protection
Unit: 2
Settings
0~9999 (is 0-19998ms)
Factory Setting: 100
This parameter is to delay the signals on PTC analog input terminals. 1 unit is 2 msec, 2 units
are 4 msec, etc.
07.18
Motor Rated Current (Motor 1)
Unit: 1
Settings
30% FLA to 120% FLA
Factory Setting: FLA
07.19
Motor No-load Current (Motor 1)
Unit: 1
Settings
0% FLA to 90% FLA
Factory Setting: 0.4*FLA
07.20
Torque Compensation (Motor 1)
Unit: 0.1
Settings
0.0 to 10.0
Factory Setting: 0.0
07.21
Slip Compensation (Used without PG) (Motor 1)
Unit: 0.01
Settings
0.00 to 10.00
Factory Setting: 0.00
07.22
Motor Line-to-line Resistance R1 (Motor 1)
Unit: 1
Settings
0 to 65535 m
Ω
Factory Setting: 0
07.23
Motor Rated Slip (Motor 1)
Unit: 0.01
Settings
0.00 to 20.00Hz
Factory Setting: 3.00
07.24
Motor Pole Number (Motor 1)
Unit: 1
Settings
2 to 10
Factory Setting: 4
07.25
Motor Rated Current (Motor 2)
Unit: 1
Settings
30% FLA to 120% FLA
Factory Setting: FLA
07.26
Motor No-load Current (Motor 2)
Unit: 1
Settings
0% FLA to 90% FLA
Factory Setting: 0.4*FLA
07.27
Torque Compensation (Motor 2)
Unit: 0.1
Settings
0.0 to 10.0
Factory Setting: 0.0
07.28
Slip Compensation (Used without PG) (Motor 2)
Unit: 0.01
Settings
0.00 to 10.00
Factory Setting: 0.00
07.29
Motor Line-to-line Resistance R1 (Motor 2)
Unit: 1
Settings
0 to 65535 m
Ω
Factory Setting: 0
07.30
Motor Rated Slip (Motor 2)
Unit: 0.01
Settings
0.00 to 20.00Hz
Factory Setting: 3.00
