Chapter 2 Installation and Wiring|
2-6 Revision June 2008, 04EE, SW--PW V1.11/CTL V2.11
Figure 4 for models of VFD-E Series
VFD022E23A/43A, VFD037E23A/43A, VFD055E23A/43A, VFD075E23A/43A, VFD110E43A,
VFD022E23C/43C, VFD037E23C/43C, VFD055E23C/43C, VFD075E23C/43C, VFD110E43C
AVI
ACI
ACM
+/B1
+10V
5K
3
2
1
Power supply
+10V 20m A
Master Fr equency
0 to 10V 47K
Analog S ignal Common
E
Main c irc ui t (power) terminals Contr ol c ircuit ter minals Shielded l eads & Cable
E
R(L1)
S(L2)
F us e/NF B(No F use B reaker)
SA
OF F ON
MC
MC
RB
RC
Recommended Circ ui t
when power suppl y
is turned O FF by a
fault output
R(L1)
S(L2)
E
Analog Multi- func ti on
Output Ter minal
factory setti ng: Analog
freq./ cur rent meter
0~ 10VDC/ 2mA
U(T1)
V(T2)
W(T3)
IM
3~
AFM
ACM
RA
RB
RC
Motor
F ac tor y setting:
Driv e is in oper ation
48V50mA Max.
Multi-function
Photocoulper Output
Analog S ignal common
E
E
MO1
MCM
MI1
MI2
MI3
MI4
MI6
MI5
DCM
+24V
F WD/Stop
REV/Stop
Multi-s tep 1
Multi-s tep 2
Multi-s tep 3
Multi-s tep 4
Digital Si gnal Common
F ac tor y
setting
Sw2
AVI
ACI
F act ory set tin g:
ACI Mod e
ACI/AVI sw itch
Wh en switch in g to AVI,
it in dicates AVI2
-
8 1
Sw1
NPN
PNP
F act ory set tin g:
NPN Mo de
Please refer to F ig u re 7
fo r w irin g of NPN
mod e an d PNP
mod e.
brake resi stor
(opti onal)
Multi-function c ontact output
Refer to c hapter2.4 for details.
F ac tor y setting is
malfunction indication
F ac tor y setting: output
frequency
4-20mA/0-10V
T(L3) T(L3)
BR
B2
RS-485 serial inter face
(NO T for VF D*E*C models)
1: Reserv ed
2: EV
5: SG +
6: Reserv ed
7: Reserv ed
8: Reserv ed
3: G ND
4: SG -
F or VFD*E*C mo dels,
p lease ref er t o figu re 8.
