Delta Electronics E48SR12007 - Manual

DATASHEET
DS_E48SR12007_05222008
FEATURES
Š High efficiency: 92.0% @ 12V/7A
Š Size: 58.4mmx22.80mmx8.4mm
(2.30”x0.90”x0.33”)
Š Standard footprint
Š Industry standard pin out
Š 2:1 Input voltage range
Š Fixed frequency operation
Š Input UVLO, Output OCP, OVP, OTP
Š 2250V isolation and basic insulation
Š No minimum load required
Š ISO 9001, TL 9000, ISO 14001, QS9000,
OHSAS18001 certified manufacturing
facility
Š UL/cUL 60950-1 (US & Canada)
recognized, and TUV (EN60950-1)
certified
Š CE mark meets 73/23/EEC and
93/68/EEC directive
APPLICATIONS
Š Telecom/Datacom
Š Wireless Networks
Š Optical Network Equipment
Š Server and Data Storage
Š Industrial/Test Equipment
OPTIONS
Š Positive On/Off logic
Š Short pin lengths
Š SMD pin
Delphi Series E48SR12007, 84W Eighth Brick
DC/DC Power Modules: 48V in, 12V/7A out
The Delphi Series E48SR12007 Eighth Brick, 48V input, single output,
isolated DC/DC converter is the latest offering from a world leader in
power systems technology and manufacturing ― Delta Electronics,
Inc. This product provides 84 watts of power with 92.0% efficiency in
an industry standard footprint. With creative design technology and
optimization of component placement, this converter possesses
outstanding electrical and thermal performances, as well as extremely
high reliability under highly stressful operating conditions.
All Delphi
E48SR models are fully protected from abnormal input/output voltage,
current, temperature conditions and also meet all safety requirements
with basic insulation.
