Chapter 4 Parameters|
4-102 Revision June 2008, 04EE, SW--PW V1.11/CTL V2.11
07.31 Motor Pole Number (Motor 2) Unit: 1
Settings 2 to 10 Factory Setting: 4
07.32 Motor Rated Current (Motor 3) Unit: 1
Settings 30% FLA to 120% FLA Factory Setting: FLA
07.33 Motor No-load Current (Motor 3) Unit: 1
Settings 0% FLA to 90% FLA Factory Setting: 0.4*FLA
07.34 Torque Compensation (Motor 3) Unit: 0.1
Settings 0.0 to 10.0 Factory Setting: 0.0
07.35 Slip Compensation (Used without PG) (Motor 3) Unit: 0.01
Settings 0.00 to 10.00 Factory Setting: 0.00
07.36 Motor Line-to-line Resistance R1 (Motor 3) Unit: 1
Settings 0 to 65535 m Ω Factory Setting: 0
07.37 Motor Rated Slip (Motor 3) Unit: 0.01
Settings 0.00 to 20.00Hz Factory Setting: 3.00
07.38 Motor Pole Number (Motor 3) Unit: 1
Settings 2 to 10 Factory Setting: 4
The motor 0 to motor 3 can be selected by setting the multi-function input terminals MI3~MI6
(Pr.04.05 to Pr.04.08) to 27 and 28.
