B.9 extension card, B.9.1 relay card – Delta Electronics AC Motor Drive VFD-E User Manual
Page 259
Appendix B Accessories|
B-22
Revision June 2008, 04EE, SW--PW V1.11/CTL V2.11
B.9 Extension Card
For details, please refer to the separate instruction shipped with these optional cards or download
from our website http://www.delta.com.tw/industrialautomation/.
Installation method
B.9.1 Relay Card
EME-R2CA Relay
Output
EME-R3AA Relay
Output
