Delta Electronics AC Motor Drive VFD-E User Manual
Page 20
Chapter 1 Introduction|
Revision June 2008, 04EE, SW--PW V1.11/CTL V2.11
1-7
Remove Keypad
1.
Press and hold in the tabs on each side
of the cover.
2.
Pull the cover up to release.
Remove Front Cover
Step 1 Step 2
Remove RST Terminal Cover
(For Frame B and Frame C)
For frame A, it doesn’t have cover and can be
wired directly.
Remove UVW Terminal Cover
(For Frame B and Frame C)
For frame A, it doesn’t have cover and can be
wired directly.
Remove Fan
Remove Extension Card
