Chapter 4 Parameters|
Revision June 2008, 04EE, SW--PW V1.11/CTL V2.11 4-5
Parameter Explanation Settings
Factory
Setting
Customer
01.17
Acceleration S-
Curve
0.0 to 10.0 / 0.00 to 10.00 sec 0.0
01.18
Deceleration S-
Curve
0.0 to 10.0 / 0.00 to 10.00 sec 0.0
0: Unit: 0.1 sec
01.19
Accel/Decel Time
Unit
1: Unit: 0.01 sec
0
01.20
Delay Time at 0Hz
for Simple Position 0.00 to 600.00 sec
0.00
01.21
Delay Time at 10Hz
for Simple Position 0.00 to 600.00 sec
0.00
01.22
Delay Time at 20Hz
for Simple Position 0.00 to 600.00 sec
0.00
01.23
Delay Time at 30Hz
for Simple Position 0.00 to 600.00 sec
0.00
01.24
Delay Time at 40Hz
for Simple Position 0.00 to 600.00 sec
0.00
01.25
Delay Time at 50Hz
for Simple Position 0.00 to 600.00 sec
0.00
01.26
Maximum Voltage
Frequency (Fbase)
(Motor 1)
0.10 to 600.0 Hz 60.00
115V/230V series: 0.1V to 255.0V 220.0
01.27
Maximum Output
Voltage (Vmax)
(Motor 1)
460V series: 0.1V to 510.0V 440.0
01.28
Mid-Point
Frequency (Fmid)
(Motor 1)
0.10 to 600.0 Hz 1.50
115V/230V series: 0.1V to 255.0V 10.0
01.29
Mid-Point Voltage
(Vmid) (Motor 1)
460V series: 0.1V to 510.0V 20.0
01.30
Minimum Output
Frequency (Fmin)
(Motor 1)
0.10 to 600.0 Hz 1.50
115V/230V series: 0.1V to 255.0V 10.0
01.31
Minimum Output
Voltage (Vmin)
(Motor 1)
460V series: 0.1V to 510.0V 20.0
01.32
Maximum Voltage
Frequency (Fbase)
(Motor 2)
0.10 to 600.0 Hz 60.00
