D.2.3 wplsoft installation – Delta Electronics AC Motor Drive VFD-E User Manual
Page 287
Appendix D How to Use PLC Function|
D-4
Revision June 2008, 04EE, SW--PW V1.11/CTL V2.11
Device
Y
ID
0
1
2
3
4
Terminals of AC
Drives
RY
MO1
-- -- --
Relay Card-2C
(EME-DR2CA)
-- --
RY2 RY3 --
Relay Card-3A
(EME-R3AA)
-- --
RY2 RY3 RY4
3IN/3OUT Card
(EME-D33A)
--
-- MO2 MO3 MO4
D.2.3 WPLSoft Installation
Download PLC program to AC drive: Refer to D.3 to D.7 for writing program and download
the editor (WPLSoft V2.09) at DELTA website
http://www.delta.com.tw/product/em/plc/plc_software.asp.
